MTS adheres to the core values of "quality, efficiency, innovation and integration" and the dedicated craftsman spirit to pool strength and build the core competitiveness in a specific field.
ARC is a high performance, high stability and high output system turret wafer sorting and taping machine independently developed and manufactured by our company. Manually place the wafer wafer cassette at the loading area (Elevator) of the machine, and the machine will automatically finish the wafer loading and the wafer blue film expanding. The chip is absorbed by the flipper and connected with the suction nozzle on the large turret. Then, the chip is tested at each station. Finally, the qualified chip is put into the braided belt mechanism for material collection.
1. Machine size：≧1700x1630x2220mm
2. machine weight：2500KG
3. Number of main turret station：24
4. Number of small turret station：8
5. Support chip size：2x2 ~ 7x7
6. acceptable wafer size：8”&12”
7. Receiving way：tape
8. Uph：≦30000 PCS
9. ailure rate：<1/3000
